RWAM 2 3/8x1 1/4 Oil Well Pump Thin Wall Barrel Series

Name: RWAM 2 38x1 14 Oil Well Pump Thin Wall Barrel Series
Brand: Zhongshi
Price: 1 USD

Brand Name : Zhongshi

Model Number : Sucker rod pump

Certification : API, ISO, QHSE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/P, T/T, Western Union, D/A

Supply Ability : 1000 SETS/MONTH

Delivery Time : 10~15 workdays

Packaging Details : Standard exported packing

Barrel type : Thin wall

Location of Seating : Top

Barrel coating : Chrome plated

Seating type : Mechanical

API No. : 11AX-0061

Model : From 20-125 to 30-250

Contact Now

RWAM Thin Wall Barrel Series Sucker Rod Pump

RWAM Thin Wall Barrel Series Sucker Rod Pump Description

The Rod Pump, Stationary Thin Wall Barrel is generally suitable for shallow well. Due to the small OD of the barrel, a larger-sized rod pump can be run in an oil well with a small-sized tubing to increase production. In addition, through the selection of fitting materials, various heat treatment processes and surface treatment processes, the requirements of well conditions for product strength, corrosion resistance and wear resistance can be met.

Technical parameter list:

Symbol	Description	Tubing Size & Pump Size
		2 3/8x1 1/4	2 3/8x1 1/2	2 7/8x2	3 1/2x2 1/2
		Complete Pump Designation
		20-125	20-150	25-200	30-250
B21	Bushing, Valve Rod	B21-20	B21-20	B21-25	B21-30
R11	Rod, Valve	R11-20	R11-20	R11-25	R11-30
C12	Cage, Top Plunger	C12-125	C12-150-20	C12-200	C12-250
P21	Plunger, One Piece	P21-125	P21-150	P21-200	P21-250
C13	Cage, Closed, Pin Plunger	C13-125	C13-150	C13-200	C13-250
V11	Traveling Valve	V11-125	V11-150	V11-200	V11-250
P12	Plug Seat	P12-125	P12-150	P12-200	P12-250
G11	Guide, Valve Rod	G11-20	G11-20	G11-25	G11-30
S21	Seating Assembly, Mechanical Top Lock	S21-20	S21-25	S21-25	S21-30
B11	Barrel, Thin Wall	B11-125	B11-150	B11-200	B11-250
C14	Cage, Closed Barrel	C14-20- 125	C14-20	C14-25	C14-30
V11	Standing Valve	V11-175	V11-175	V11-225	V11-250
B22	Bushing, Seat, Barrel Cage	B22-20	B22-20	B22-25	B22-30
N14	Nipple, Seating, Mechanical Top Lock	N14-20	N14-25	N14-25	N14-30

.
1. Top mechanical seating sucker rod pump

2. Stationary thin wall barrel

3. High temperature resistance

RWAM 2 3/8x1 1/4 Oil Well Pump Thin Wall Barrel Series
