Alloy Steel Material Well Pump Tubing 20-150RHBM-16-4-2-2 With Pump Barrel

  • 1
  • 2

Brand Name : Zhongshi

Model Number : Sucker rod pump

Certification : API 11AX

Place of Origin : China

MOQ : 1pcs

Price : Negotiable

Payment Terms : D/P, T/T

Supply Ability : 1000 SETS/MONTH

Delivery Time : 10~15 workdays

Packaging Details : Standard exported packing

Standard : API

Material : Alloy Steel

Type : Sucker rod pump

Color : Customized

Use : Oil Production

Contact Now

Alloy Steel Material Well Pump Tubing 20-150RHBM-16-4-2-2 With Pump Barrel

Product Description:

After being assemblied on the surface, the rod pump is run into the well and seated inside the seating nipple. There is no need to lift the tubing, which reduces operation time and cost, frequency of turning on and off tubing threads, and prolongs run life of the tubings.

The rod pump can be classified into mechanical type(M) and cup type(C) according to the tupe of seating assembly. Also it is divided into three types as RHA(stationary heavy well barrel top anchor rod pump), RHB(stationary heavy well barrel bottom anchor rod pump) and RHT(travelling heavy well barrel bottom anchor rod pump), depending where the seating assembly is positioned.

Technical parameter

Specification Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Tubing size EUE(in)
15-106RHBM Ø26.99 2.1-10.4 0.3-8.0 1.2-9.0 1.9”
20-125RHBM Ø31.75 2-3/8”
25-150RHBM Ø38.10 2-7/8”
25-175RHBM Ø44.45 2-7/8”
30-225RHBM Ø57.15 3-1/2”

Alloy Steel Material Well Pump Tubing 20-150RHBM-16-4-2-2 With Pump Barrel

Features

1. Safety, environmental protection and energy saving.

2. Large translating, pumping sand size range.

3. Equipped with punch, reduce the operation cost.

4. Reasonable structure and long service life.

Alloy Steel Material Well Pump Tubing 20-150RHBM-16-4-2-2 With Pump Barrel
