P110 Steel Grade Seamless Casing Pipe 4 1/2 Inch For Well Wall Cementing

Name: P110 Steel Grade Seamless Casing Pipe 4 12 Inch For Well Wall Cementing
Brand: Zhongshi
Price: 1 USD

Brand Name : Zhongshi

Model Number : 4 1/2"-20"

Certification : API 5CT

Place of Origin : China

MOQ : One metric ton

Price : Negotiable

Payment Terms : L/C, T/T

Packaging Details : Be bundled by steel strap

Structure : Seamless pipe

Steel grade : P110

Threads : LTC, BTC

Norminal weight : 9.5# 10.5# 11.6# 13.5# 15.1#

Type : Oil pipe

Application : Well wall cementing

Contact Now

P110 Steel Grade Seamless Casing Pipe 4 1/2 Inch OD LTC And BTC Threads

Casing pipe description:

Casing pipe is the major structural component of a well. The API 5CT Casing pipe is a large-diameter

steel pipe that serves as the structural retainer for the walls of oil and gas wells, and typically held into

place with cement.

API 5CT casing is inserted into a well bore and cemented in place to protect both subsurface formations

and the wellbore from collapsing and to allow drilling fluid to circulate and extraction to take place.

The cost of casing is a major part of the overall well cost, so selection of casing size, grade, connectors,

and setting depth is a primary engineering and economic consideration.

Features:

1. P110 steel grade
2. Size OD 4 1/2"

3. Quality alloy steel

Technical specifications:

Steel grade :	P110
Out Diameter:	4 1/2"
Wall Thickness:	5.21-8.56mm
Length::	R3
Standards:	API 5CT
Application:	Oil well wall cementing
Packing:	By steel strap or packing frame

Mechanical properties:

Standard	Steel Grade	Tensile Strength(MPa)	Yield strength(MPa)	Elongation(%)	Hardness
API 5CT	J55	≥517	379~552	As API 5CT
	K55	≥655	379~552
	N80	≥689	552~758
	L80(13Cr)	≥655	552~655		≤241HB
	P110	≥862	758~965

P110 Steel Grade Seamless Casing Pipe 4 1/2 Inch For Well Wall Cementing
