High Performance 38CrMoA Alloy Steel Sucker Rod Pump With Chorme Pump Barrel

Name: High Performance 38CrMoA Alloy Steel Sucker Rod Pump With Chorme Pump Barrel
Brand: Zhongshi
Price: 1 USD

High Performance 38CrMoA Alloy Steel Sucker Rod Pump With Chorme Pump Barrel Manufactures

Brand Name : Zhongshi

Model Number : Sucker rod pump

Certification : API, ISO, QHSE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/P, T/T, Western Union, D/A

Supply Ability : 1000 SETS/MONTH

Delivery Time : 10~15 workdays

Packaging Details : Standard exported packing

Standard : API 11Ax

Material : 38CrMoA,alloy steel

Type : Rod Pump,RHBM-ARWAC

Application : Oil,petroleum production

Length : As request

Plunger length (ft) : 2-24

Contact Now

High Performance 38CrMoA Alloy Steel Sucker Rod Pump With Chorme Pump Barrel

Product Description

The work over process of tubing pump is: firstly the barrel being connected to the tubing is directly run into the well at desired depth and then the plunger is run into the barrel with the sucker rod. The applicable tubing pump is larger in size than rod pump in the same tubing. Tubing pump has simple structure so the displacement is bigger and it is suitable for the shallower well with shallow depth and high production.

The THD type of tubing pump means that its standing valve is directly connected to the barrel and it cannot be pulled up separately with the barrel. The THC or THM type of tubing pump means that its standing valve can be pulled up separately with the barrel. The seating assembly of THC pump is cup type and for THM is mechanical type. The THC and THM type of tubing pump are suitable for the frequently work-over wells.

Technical Specifications:

Specification	Nominal Bore mm(in)	Plunger Length m(ft)		Max. O.D. mm	Rod in	Tubing in	Pump Constant m3/d	Stroke m
20-125 TH	32 (1.25)	1.2-1.8(4-6)	73		3/4	2-3/8	1.14	≤8.0
25-125 TH	32 (1.25)		88.9		3/4	2-7/8	1.14
20-150 TH	38 (1.50)		73		3/4 (5/8)	2-3/8	1.64
25-150 TH	38 (1.50)		88.9		3/4 (5/8)	2-7/8	1.64
20-175 TH	44 (1.75)		73		3/4	2-3/8	2.24
25-175 TH	44 (1.75)		88.9		3/4	2 7/8	2.24
25-200 TH	51 (2.00)		88.9		3/4	2-7/8	2.91
25-225 TH	57 (2.25)		88.9		3/4	2-7/8	3.69
25-250 TH	64 (2.50)		88.9		3/4	3-1/2	4.55
30-275 TH	70 (2.75)		108		7/8	3-1/2	5.50
35-325 TH	83 (3.25)		116		7/8	4	7.70
40-375 TH	95 (3.75)		116		1	4-1/2	10.26
35-425 TH	108 (4.25)		147		1-1/8	4	13.18

Features:

1. According to API Spec 11AX

2. Suitable for the shallow well with shallow depth and high production

3. The barrel being connected to the tubing is directly run into the well

4. The plunger is run into the barrel with the sucker rod

High Performance 38CrMoA Alloy Steel Sucker Rod Pump With Chorme Pump Barrel

Product Tags:

oil sucker pump

gas anchor rod pump

High Performance 38CrMoA Alloy Steel Sucker Rod Pump With Chorme Pump Barrel Images
