Carbon Steel Downhole Rod Insert Pump For Oil Production

Brand Name : Zhongshi

Model Number : RHAC

Certification : API, ISO, QHSE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/P, T/T, Western Union, D/A

Supply Ability : 1000 SETS/MONTH

Delivery Time : 10~15 workdays

Packaging Details : Standard exported packing

Pump material : Carbon steel in usual

Application : Oil production pump

Pump structure : Inserted

Plunger end : Pin end

Plunger type 1 : Plain surface

Plunger type 2 : With sand slotting

Valve ball & seat : Double valve

Fittings material : Carbon steel or low alloy steel

Contact Now

Carbon Steel Oil Production Downhole Rod Inserted Pump

Oil production downhole rod inserted pump description:

Based on the conventional subsurface pumps, a series of special purpose pumps were developed, which can apply to different well conditions.

Rod pump is equipped with a support joint, support joint connected on the tubing string, and it is together with the tubing string down to the bottom. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work.

Rod pump should be installed inside the tubing with the sucker rod. It is not necessary to pull the tubing out of the well when checking the pump, which can make the operation easier and quicker.

RHBC rod inserted pump Technical specifications:

RHBC model Pump OD (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in) Sucker rod size
15-106RHBC Ø26.99 2.1-10.4 0.3-8.0 1.2-9.0 0.3-0.9 1.9”

CYJ16

CYJ19
20-125RHBC Ø31.75 2-3/8”
25-150RHBC Ø38.10 2-7/8”
25-175RHBC Ø44.45 2-7/8”
30-225RHBC Ø57.15 3-1/2”

Packing photo for inserted pump:

Carbon Steel Downhole Rod Insert Pump For Oil Production
